Chengrui has been exporting machines to set up concertina razor barbed wire production line in various premises. Major importers and distributors of our machinery are from Egypt, Malaysia, Turkey, Brazil and other countries.
Machine Features: Light, easy to operate, high efficient, material saving.
Structure: Two parts: the main machine for producing strip plates by punching sheets, and the coiling machine.
Well Sold Machine Models
Barbed Wire Punching Machine
Barbed Wire Making Machines (Punching Machine), Export to Turkey for Blade BTO-12 OR BTO-22 Razor Type Barbed Wire
Equipment for Manufacturing of Razor Blade Type Barbed Wire, Hot Dip Galvanized. Major Unit Out Size: 1100mmx750mmx1200mm
Model | Five strip/ Nine strip |
Voltage | 380V, 50Hz or client’s required voltage |
Power | 2.2kw |
Producing speed | 220-280m/h |
Thickness | 0.5±0.05mm |
Pressure | 25ton/ 40ton |
Weight | 1500kg/ 2200Kg |
Dimension | 1100mm×1000mm×2000mm |
Voltage | 380V, 50Hz,or client’s required voltage |
Power | 1.5kw |
Producing speed | 80Kg/h |
Wire diameter | 2.5mm |
Weight | 300Kg |
Dimension | 1100mm×750mm×1200mm |
Barb Length | Barb width | Barb spacing |
12±1mm | 13±1mm | 26±1mm |
12±1mm | 15±1mm | 26±1mm |
18±1mm | 15±1mm | 33±1mm |
22±1mm | 15±1mm | 34±1mm |
28±1mm | 15±1mm | 34±1mm |
30±1mm | 18±1mm | 34±1mm |
60±1mm | 32±1mm | 96±1mm |
65±1mm | 21±1mm | 100±1mm |
Overal Diamension | L*W*H：1100mmx750mmx1200mm |
Rated Voltage | 380V |
Power | 1.5kw |
Producing speed | 80kg/h |
Weight | 300kg |
Overal Diamension | L*W*H: 1200MMX1000MMX1900MM |
Rated Voltage | 380V |
Power | 2.2KW |
Producing speed | 220-280m/h |
Weight | 1500KG |
Overal Diamension | L*W*H：1100mmx750mmx1200mm |
Rated Voltage | 380V |
Power | 1.5kw |
Producing speed | 80kg/h |
Weight | 300kg |
Coil Dia.(mm) | 500 | 700 | 960 | 450 |
Number of Circles | 56 | 72 | 52 | 33 |
Standard Covered Length (m) | 8-9 | 11-13 | 8-10 | 8 |
Maximal Covered Length | 12 | 15 | 13 | 12 |
